Features:

1. Stable performance and high reliability

2. Small size, fast induction, high sensitivity

3. Good heat cycle resistance

4. Adopt epoxy resin encapsulation

5. Epoxy encapsulated head size can reach ±2.0mm

Application:

1. Household appliances, computers

2. New energy vehicle battery pack

4. Boiling the kettle

5. BMS battery system, battery components

6. Air temperature

7. Power Bank

Electrical characteristics:

1. Thermal reaction time: ≤10 seconds in water bath

2. Dissipation coefficient: about 2.6mW/℃ in the static air

3. Withstand voltage test: AC 1000V 2mA for 3 seconds

4. Insulation test: DC 500V ≥100MΩ

5. Rated power: ≤10mW

6. Operating temperature: -30℃～100℃

Outline structure drawing:

Download Google:

Please inform the following parameters when ordering NTC temperature sensor:

1. What is the resistance requirement (can be selected according to the above table)

2. How much B value is required (can be selected according to the above table)

3. Working environment (whether it needs to be waterproof, moisture-proof, cold-resistant, etc.)

4. Purpose: Choose different temperature-resistant wires, different resistance values for different purposes, etc.

5. What is the operating temperature range?

6. Accuracy requirements (1%-5% optional)

7. Shell material (copper, brass, stainless steel, ABS, epoxy resin, etc.)

8. Shell size (all can be customized)

9. Wire and length (both can be customized)

10. Does the end of the wire need a connector? (Molex, JST, CJT, etc. are optional).

Conventional resistance R-T table:
