Features:

1. The resistance value and B value have high precision, good consistency and interchangeability

2. Good insulation, high reliability, fast response speed,

3. The double-layer sealing process is adopted, which has good insulation and sealing performance and anti-mechanical collision, anti-bending ability, and high reliability

4. Can work stably for a long time (annual resistance value drift rate ≤ 1‰)

5. It can be packaged according to the installation conditions used, which is convenient for users to install.

Application:

1. Household air-conditioning tuyere temperature, automobile air-conditioning, refrigerator, freezer, water heater, water dispenser, heater

2. Temperature measurement and control in dishwashers, disinfection cabinets, washing machines, dryers, dryers, medium and low temperature drying ovens, constant temperature ovens, etc.

3. Medical equipment, temperature control instruments, electronic gifts, electronic temperature and humidity, automobile temperature measurement, electronic calendar, rechargeable battery pack and charger.

Electrical characteristics:

1. Thermal response time: maximum 6 seconds in water bath

2. Dissipation coefficient: about 2.6mW/℃ in the static air

3. Withstand voltage test: 2mA for 1 second, no flashover, no breakdown and other abnormal phenomena in the steel ball

4. Insulation test: ≥100MΩ in steel ball

5. Rated power: 10mW

6. Operating temperature: -30℃～150℃

Download Google:

Please inform the following parameters when ordering NTC temperature sensor:

1. How much resistance is required (can be selected according to the above table)

2. How much B value is required (can be selected according to the above table)

3. Working environment (whether waterproof, moisture-proof, cold-resistant and others are required)

4. Purpose: Choose different temperature-resistant wires for different purposes, different resistance values, etc.

5. What is the operating temperature range?

6. Accuracy requirements (1%-5% optional)

7. Shell material (copper, brass, stainless steel, ABS, epoxy resin, etc.)

8. Shell size (all can be customized)

9. Wire and length (all can be customized)

10. Does the end of the wire need a connector? (Molex, JST, CJT, etc. are optional).

Conventional resistance R-T table:
