Features:

1. Fast induction speed and high sensitivity

2. High precision of resistance value and B value

3. SUS304 stainless steel material shell, excellent corrosion resistance

4. Adopt double-layer sealing process, with good insulation and sealing performance

5. Good stability and long life

6. Accept customization

7. Equipped with sealing ring, easy installation and reliable sealing

Application:

1. Water heater system, wall-hung boiler water heater

2. Biological incubator,

3. Foot bath, etc.

4. Beauty Oven, etc.

Electrical characteristics:

1. Thermal response time: maximum 3 seconds in water bath

2. Dissipation coefficient: about 1.3mW/℃ in the static air

3. Withstand voltage test: 2mA for 1 second, no flashover, no breakdown and other abnormal phenomena in the steel ball

4. Insulation test: 100MΩ, ≥100MΩ in steel ball

5. Rated power: 5mW

6. Operating temperature: -20℃～125℃

Outline structure drawing:

Download Google:

Please inform the following parameters when ordering NTC temperature sensor:

1. What is the resistance requirement (can be selected according to the above table)

2. How much B value is required (can be selected according to the above table)

3. Working environment (whether it needs to be waterproof, moisture-proof, cold-resistant, etc.)

4. Purpose: Choose different temperature-resistant wires, different resistance values for different purposes, etc.

5. What is the operating temperature range?

6. Accuracy requirements (1%-5% optional)

7. Shell material (copper, brass, stainless steel, ABS, epoxy resin, etc.)

8. Shell size (all can be customized)

9. Wire and length (both can be customized)

10. Does the end of the wire need a connector? (Molex, JST, CJT, etc. are optional).

Conventional resistance R-T table:
