Features:

1. High sensitivity and rapid response

2. Small structure, easy installation, good waterproof

3. Wide operating temperature zone, good stability and high reliability

4. Products with different R and B values can be provided, with strong interchangeability and high precision

5. Bullet shell packaging

Application:

1. a water heater

2. Shower, disinfection cabinet, washing machine, soymilk machine, air conditioner, induction cooker, microwave oven, washing machine

3. Temperature measurement of granary, refrigerator, air conditioner, electric water heater, freezer, mobile phone battery, charger, induction cooker, bread maker, disinfection cabinet

4. Electric oven, fire alarm, food storage, ocean, deep well, glacier temperature measurement, military industry and other fields.

Electrical characteristics:

1. Thermal reaction time: ≤3 seconds in water bath

2. Dissipation coefficient: about 2.6mW/℃ in the static air

3. Withstand voltage test: AC 1300V 2mA for 1 second, no flashover, no breakdown and other abnormal phenomena in the steel ball

4. Insulation test: ≥100MΩ

5. Rated power: ≤10mW

6. Operating temperature: 0℃～120℃

Outline structure drawing:

Download Google:

Please inform the following parameters when ordering NTC temperature sensor:

1. What is the resistance requirement (can be selected according to the above table)

2. How much B value is required (can be selected according to the above table)

3. Working environment (whether it needs to be waterproof, moisture-proof, cold-resistant, etc.)

4. Purpose: Choose different temperature-resistant wires, different resistance values for different purposes, etc.

5. What is the operating temperature range?

6. Accuracy requirements (1%-5% optional)

7. Shell material (copper, brass, stainless steel, ABS, epoxy resin, etc.)

8. Shell size (all can be customized)

9. Wire and length (both can be customized)

10. Does the end of the wire need a connector? (Molex, JST, CJT, etc. are optional).

Conventional resistance R-T table:
