Features:

1. Good stability and high reliability

2. Due to the purchase of glass packaging, it can be used in harsh environments such as high temperature and high humidity

3. Small size, sturdy structure, easy for automatic installation

4. Adopt brand-new technology, can work for a long time. (Annual resistance drift rate≤1%)

5. Cost-effective, economical and practical.

6. Glass package, high temperature resistance, fast response

Application:

1. Laser Printer

2. Temperature detection and temperature compensation of office automation equipment (such as copiers, printers, etc.)

3. Temperature control and detection of industrial, medical, environmental, meteorological, and food processing equipment

4. Automobile air conditioners, refrigerators, freezers, water heaters, drinking water.

Electrical characteristics:

1. Thermal response time: max 3 seconds in water bath

2. Withstand voltage test: AC 1300V 2mA for 1 second, no flashover, no breakdown and other abnormal phenomena in the steel ball

3. Insulation test: ≥100MΩ

4. Operating temperature: 0℃～250℃

Electrical Specifications:

Outline structure drawing:

Download Google:

Please inform the following parameters when ordering NTC temperature sensor:

1. What is the resistance requirement (can be selected according to the above table)

2. How much B value is required (can be selected according to the above table)

3. Working environment (whether it needs to be waterproof, moisture-proof, cold-resistant, etc.)

4. Purpose: Choose different temperature-resistant wires, different resistance values, etc. for different purposes

5. What is the operating temperature range?

6. Accuracy requirements (1%-5% optional)

7. Shell material (copper, brass, stainless steel, ABS, epoxy resin, etc.)

8. Shell size (all can be customized)

9. Wire and length (both can be customized)

10. Does the end of the wire need a connector? (Molex, JST, CJT, etc. are optional).

Conventional resistance RT table:
