Mitsubishi DSAHR series surge suppressor
Number of Views:59332021-06-23 10:57:13
Used for surge protection in circuits that require greater surge withstand capability.
| Rated voltage | Model |
DC discharge start voltage (Vs) |
Insulation resistance (IR) |
|
| AC 125V | DSAHR-1 | 500V（400〜600） | 100MΩmin. | DC 100V |
| AC 250V | DSAHR-3 | 800V（640〜960） | DC 250V | |
| DC 450V | DSAHR-4 | 1,200V（960〜1,440） | DC 450V | |
| DC 600V | DSAHR-5 | 1,500V（1,200〜1,800） | DC 600V | |
| Model |
Electrostatic capacity 1kHz-6V max. |
Surge tolerance 8/20μsec. |
Surge life 8/20μsec. 100A |
UL certified products |
|
1） UL1449 |
||||
| DSAHR-1 | 5pF max. | 5,000A | 300 times | ○ |
| DSAHR-3 | ○ | |||
| DSAHR-4 | ○ | |||
| DSAHR-5 | ○ |
1): UL Standard UL 1449 File No. E318314
