Features:

1. Stable performance and high reliability

2. High thermal conductivity

3. Good water resistance

4. Quick response

5. High sensitivity

6. The resistance value and B value have high precision, good consistency and interchangeability

7. Accept customization

Application:

1. Coffee machine, smart toilet

2. Microwave oven, air conditioner, inverter, induction cooker

3. Heaters, freezers, water dispensers, disinfection cabinets, washing machines, soymilk machines

4. Rice cooker, oven, electric car, soymilk machine

Electrical characteristics:

1. Thermal reaction time: ≤3 seconds in water bath

2. Dissipation coefficient: about 1.3mW/℃ in the static air

3. Withstand voltage test: 2mA for 1 second, no flashover, no breakdown and other abnormal phenomena in the steel ball

4. Insulation test: ≥100MΩ

5. Rated power: ≤5mW

6. Operating temperature: -20℃～105℃

Outline structure drawing:

Order notice:

Please inform the following parameters when ordering NTC temperature sensor:

1. What is the resistance requirement (can be selected according to the above table)

2. How much B value is required (can be selected according to the above table)

3. Working environment (whether it needs to be waterproof, moisture-proof, cold-resistant, etc.)

4. Purpose: Choose different temperature-resistant wires, different resistance values, etc. for different purposes

5. What is the operating temperature range?

6. Accuracy requirements (1%-5% optional)

7. Shell material (copper, brass, stainless steel, ABS, epoxy resin, etc.)

8. Shell size (all can be customized)

9. Wire and length (both can be customized)

10. Does the end of the wire need a connector? (Molex, JST, CJT, etc. are optional).

Conventional resistance RT table:
