Features:

1. Product working temperature is high (300℃);

2. Under high temperature conditions, the material will not change color, will not be brittle, will not harden;

3. Good product stability and high reliability;

4. Large-scale production, high cost performance;

5. Product accuracy is stable.

Application:

1. Industrial furnaces, high temperature environments, controlled ovens, microwave ovens, washing machines and dryers, dishwashers and small appliances-toasters

2. Blender, hair dryer, curling tongs, shower, air conditioner, stove, refrigerator

3. Rice cookers, ovens, water heaters, heaters, refrigerators, water dispensers, disinfection cabinets, washing machines, soymilk machines

4. The temperature of the refrigerator and monitor the temperature on the rechargeable Ni-Cr battery.

Electrical characteristics:

1. Withstand voltage test: 2mA for 1 second, no flashover, no breakdown and other abnormal phenomena in the steel ball

2. Insulation test: ≥100MΩ

3. Operating temperature: -30℃～300℃ (head temperature resistance 300℃, other parts temperature resistance 250℃)

Download Google:

Please inform the following parameters when ordering NTC temperature sensor:

1. How much resistance is required (can be selected according to the above table)

2. How much B value is required (can be selected according to the above table)

3. Working environment (whether waterproof, moisture-proof, cold-resistant and others are required)

4. Purpose: Choose different temperature-resistant wires for different purposes, different resistance values, etc.

5. What is the operating temperature range?

6. Accuracy requirements (1%-5% optional)

7. Shell material (copper, brass, stainless steel, ABS, epoxy resin, etc.)

8. Shell size (all can be customized)

9. Wire and length (all can be customized)

10. Does the end of the wire need a connector? (Molex, JST, CJT, etc. are optional).

Conventional resistance RT table:
