Features:

1. High sensitivity and rapid response

2. Small structure, easy installation, good waterproof

3. Wide operating temperature zone, good stability and high reliability

4. Products with different R and B values can be provided, with strong interchangeability and high precision

Application:

1. Smart rice cooker

2. Pressure cooker

3. Household appliances

Product parameters:

Electrical characteristics:

1. Thermal response time: maximum 15 seconds in a water bath

2. Insulation test: DC 500V ≥100MΩ

3. Dissipation coefficient: about 2.0mW/℃ in the static air

4. Rated power: 10mW

5. Withstand voltage test: AC 2000V 2mA 6 seconds

6. Operating temperature: -40℃～200℃

Download Google:

Please inform the following parameters when ordering NTC temperature sensor:

1. What is the resistance requirement (can be selected according to the above table)

2. How much B value is required (can be selected according to the above table)

3. Working environment (whether it needs to be waterproof, moisture-proof, cold-resistant, etc.)

4. Purpose: Choose different temperature-resistant wires, different resistance values for different purposes, etc.

5. What is the operating temperature range?

6. Accuracy requirements (1%-5% optional)

7. Shell material (copper, brass, stainless steel, ABS, epoxy resin, etc.)

8. Shell size (all can be customized)

9. Wire and length (both can be customized)

10. Does the end of the wire need a connector? (Molex, JST, CJT, etc. are optional).

Conventional resistance R-T table:
